Door Access Controller for Waterproof Metal Access Control

Sales Door Access Controller for Waterproof Metal Access Control

> Card type: EM or EM+HID Card

> One relay, 1000 users

> User data can be transferred by Wiegand line

> Access modes: Card, PIN, Card + PIN, Multi Cards/PINs

> PIN length: 4~6 digits

> Pulse mode, toggle mode

> 2pcs device support interlock for two doors


Product Detail

Waterproof Metal Access Control

Model No.: XK1 EM, EM+HID


> One relay, 1000 users

> User data can be transferred by Wiegand line

> Access modes: Card, PIN, Card + PIN, Multi Cards/PINs

> Card type: XK1-EM: 125KHz EM card

                     XK1-EH: 125KHz EM & HID card

> PIN length: 4~6 digits

> Pulse mode, toggle mode

> 2pcs device support interlock for two doors


User Capacity

1000

Common User

998

Panic User

2

Operating Voltage

12~28V AC/DC

Idle Current

< 35mA

Proximity Card Reader

EM, EM&HID

Radio Technology

125KHz Proximity Card

Read Range

2~6 cm

Wiring Connections

Relay output, exit button, alarm, door contact, Wiegand input, Wiegand output

Relay

One (NO, NC, Common)

Adjustable Relay Output Time

0~99 Seconds (5 seconds default)

Lock Output Load

2 Amp Maximum

Wiegand Interface

Wiegand 26~37bits

Wiegand Input

26~37bits

Wiegand Output

26~37bits

PIN Output

4 bits, 8 bits(ASCII), 10 digits Virtual Number

Environment

Meets IP66

Operating Temperature

-40℃ ~ 60℃ (-40°F ~ 140°F)

Operating Humidity

0%RH ~ 98%RH

Physical

Zinc-Alloy

Colour

Silver

Dimensions

11.5L x 7.5W x 2.2H (cm)

Unit Weight

360g

Shipping Weight

440g

Waterproof Metal Access Control
